Side Tilt Carriages - There are actually 4 sizes of hook type tine carriages rated by the fork carriage lifting capacity. Hook type fork carriages have been the same.
Class I carriages are rated for loads up to 2000 lbs. The carriage bar spacing utilized for Class I is thirteen inches. Class II carriages are rated for cargo up to 5,550 lbs. Their carriage bar spacing is 16 inches. Class III carriages are rated for cargo as much as 10,000 lbs. The carriage bar spacing for this class is twenty inches. Class IV carriages are rated for cargo as much as 15,500 lbs. The carriage bar spacing for this capacity is twenty five inches.
Pin mounted tines vary by the amount of offset between the fork and the fork eye. Some manufacturers will differ the carriages for pin type blades. Carriage capacity will be established by the carriage pin size and by the blade size.
